FineBI is a Business Intelligence product launched by FanRuan Software Co., Ltd. FineBI is a new-generation big data analytics BI tool designed to help business personnel fully understand and utilize their data. This article describes how to use the MySQL protocol to connect to Lakehouse.

Prerequisites

Please refer to the FineBI official website. If already installed, skip this step.
Use the MySQL protocol to connect. Currently, you need to reset your password, even for newly created accounts. This is because MySQL 5.x uses the
```
mysql_native_password
```
mysql_native_password
authentication plugin, while Lakehouse needs to store the MySQL encryption algorithm. Currently, Lakehouse only saves the MySQL key encryption algorithm when the password is changed. You can reset the password to the same value as before to avoid affecting other task connections.
Set a compute cluster for the user. Since the MySQL protocol does not provide a way to pass the cluster setting, users can use SQL commands to assign a default compute cluster to a user. This way, the designated cluster will be used when connecting via MySQL.
- ALTER USER user_name SET DEFAULT_VCLUSTER = default; -- Check if the cluster setting is effective SHOW USERS;
Prepare the username. The MySQL protocol connection address can only accept a single URL and cannot concatenate the Lakehouse instance name and workspace name. Therefore, you need to concatenate the instance name and workspace name into the username.
- The username format is as follows:
- login_account_name@instance_name.workspace_name
- Obtain instance_name: Get the JDBC connection string from the workspace page. For example, in
```
jdbc:clickzetta://``jnsxwfyr.api.singdata.com/quick_start?virtualCluster=default
```
  jdbc:clickzetta://``jnsxwfyr.api.singdata.com/quick_start?virtualCluster=default
  ,
```
jnsxwfyr
```
  jnsxwfyr
  is the instance_name.
- Obtain workspace_name: The name of the workspace.

Configuring FineBI to Connect to Lakehouse

Navigate to Data Connection -> Data Connection Management -> New Data Connection -> Select MySQL
Fill in the configuration information, as shown in the following example

Field Name	Description
Data Connection Name	Custom connection name, e.g.: clickzetta_lakehouse_mysql
Driver	Use the default value: com.mysql.jdbc.Driver
Database Name	Lakehouse schema name, e.g.: public
Host	Connection address for each region. See Connect using MySQL protocol for details
Port	Optional. Default: 3306
Username	login_account_name@instance_name.workspace_name
Password	Password for the login account
Encoding	Default value
Data Connection URL	FineBI will automatically generate the URL based on the above connection information. You need to edit the URL and append `?useSSL=false` ?useSSL=false at the end. This parameter is required for connectivity. Example: jdbc:mysql://``cn-shanghai-alicloud-mysql.api.singdata.com/dws_clys?useSSL=false jdbc:mysql://``cn-shanghai-alicloud-mysql.api.singdata.com/dws_clys?useSSL=false . After adding this parameter, the database name will also have `?useSSL=false` ?useSSL=false appended, e.g.: `public?useSSL=false` public?useSSL=false . This is normal.
